Victron Energy Orion-Tr Smart 12/12-18A (220W) Isolated DC-DC Charger – ORI121222120

Victron Energy Orion-Tr Smart 12/12-18A (220W) Isolated DC-DC Charger – ORI121222120

Regular price £116.42 GBP
Regular price £184.80 GBP Sale price £116.42 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.

Product Overview

The Victron Energy Orion-Tr Smart 12/12-18A Isolated DC-DC Charger, part number ORI121222120, is an intelligent battery-to-battery charger designed to charge a 12V auxiliary battery from a 12V vehicle, leisure or marine electrical system. Providing up to 18A of continuous output current at 40°C and 220W of continuous power, it delivers controlled and efficient charging for a wide range of mobile and off-grid applications.

Featuring built-in Bluetooth connectivity, galvanic isolation and a programmable adaptive charging algorithm, the Orion-Tr Smart offers excellent flexibility for different battery technologies. It is suitable for lead-acid, AGM, gel and compatible lithium battery systems, making it an excellent choice for motorhomes, campervans, boats, commercial vehicles and dual-battery installations.

Usage and Applications

The Victron Orion-Tr Smart 12/12-18A is particularly useful in vehicles and boats where a secondary battery needs to be charged from the starter battery and alternator while the engine is running. It provides controlled charging between the two battery banks, helping protect the starter battery from unnecessary discharge when the engine is switched off.

Typical applications include motorhome leisure batteries, campervan electrical systems, marine service batteries, auxiliary vehicle batteries and independent off-grid installations. It can be configured to charge compatible 12V lead-acid or lithium batteries, with charging settings selected to suit the battery manufacturer's requirements.

The Orion-Tr Smart also offers a fixed-output power supply mode, allowing it to provide a regulated DC voltage for suitable equipment rather than operating as a battery charger. This makes it a versatile component for a variety of 12V electrical installations.

Technical Information and Features

The Orion-Tr Smart incorporates Bluetooth Smart technology, allowing users to configure, monitor and update the charger through the VictronConnect application on a compatible smartphone or tablet. Charging parameters can be adjusted, battery profiles selected and operating information viewed wirelessly.

Its adaptive three-stage charging algorithm consists of bulk, absorption and float charging. During bulk charging, the charger delivers the available charging current to replenish the battery. Absorption charging then regulates the voltage to complete the charging process, while float charging maintains the battery at an appropriate voltage. Adaptive absorption helps prevent unnecessary overcharging of lead-acid batteries, while configurable settings support lithium battery applications.

Smart alternator compatibility is provided through built-in engine shutdown detection. This helps ensure that charging takes place when the engine is running and prevents unnecessary discharge of the starter battery. The unit can also be controlled through its remote on/off connection or the VictronConnect application.

Galvanic isolation rated at 200V DC is provided between the input, output and case. This is particularly beneficial in marine and vehicle installations where separate electrical circuits need to remain electrically isolated.

The charger incorporates overload, short-circuit and over-temperature protection. Output power is automatically reduced at high ambient temperatures to help protect the equipment. Multiple compatible Orion-Tr Smart chargers can be connected in parallel to increase the available charging current.

Product Specifications

The Victron Energy ORI121222120 has an input voltage range of 8–17V DC, with undervoltage shutdown at 7V and restart at 7.5V. Its nominal output voltage is 12.2V DC, adjustable between 10V and 15V.

Continuous output current is rated at 18A at 40°C, with a maximum output current of 25A for 10 seconds. Short-circuit output current is 40A. Continuous output power is rated at 280W at 25°C and 220W at 40°C. Maximum efficiency is 87%, and no-load input current is less than 80mA. Standby current is less than 1mA.

Output voltage tolerance is ±0.2V, with output noise of 2mV RMS. Galvanic isolation is rated at 200V DC between input, output and case.

The operating temperature range is -20°C to +55°C, with output derating of 3% per °C above 40°C. Maximum permitted humidity is 95% non-condensing.

Electrical connections are made using screw terminals, supporting cable cross-sections up to 16mm² (AWG6). The unit measures approximately 130 x 186 x 70mm and weighs 1.3kg. Its IP43 protection rating applies when installed with the screw terminals facing downwards.

Why Choose Victron Energy?

Victron Energy is internationally recognised for producing dependable battery charging, power conversion and energy management equipment. The Orion-Tr Smart range combines intelligent charging technology with Bluetooth monitoring, programmable charging profiles and flexible installation options.

The Victron Orion-Tr Smart 12/12-18A Isolated DC-DC Charger provides a reliable solution for charging an auxiliary 12V battery from a vehicle or marine electrical system. Its smart alternator compatibility, adaptive charging, galvanic isolation and remote control make it a versatile choice for modern dual-battery installations.

SKU:ORI121222120
