Victron

Orion-Tr 48/24-5A (120W) Isolated DC-DC converter

Orion-Tr 48/24-5A (120W) Isolated DC-DC converter

Regular price £46.11 GBP
Regular price £73.19 GBP Sale price £46.11 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.


Product Overview

The Victron Energy Orion-Tr 48/24-5A Isolated DC-DC Converter, part number ORI482410110, is a compact and reliable voltage converter designed to transform power from a 48V DC battery system into a regulated 24V DC supply. With a continuous output current of 5A and a power rating of 120W at 25°C, it provides an effective solution for powering 24V equipment from a higher-voltage battery bank.

The Orion-Tr features galvanic isolation between the input, output and case, helping to maintain electrical separation between circuits. Its adjustable output voltage, remote on/off facility and parallel operation capability make it suitable for a wide range of marine, vehicle, industrial and off-grid electrical installations.

Usage and Applications

The Victron Orion-Tr 48/24-5A is designed for systems where a 48V battery bank needs to supply 24V electrical equipment. It is suitable for boats, motorhomes, commercial vehicles, renewable energy installations, industrial control systems and off-grid power applications.

It can provide a stable 24V supply for compatible lighting, pumps, communication equipment, monitoring systems, control electronics and other DC-powered accessories. The adjustable output voltage also allows the converter to be configured for charging a suitable 24V starter or auxiliary battery, provided the correct charging voltage and control arrangements are used.

For applications requiring greater output current, multiple compatible Orion-Tr converters can be connected in parallel. This allows the available output capacity to be increased to suit larger 24V electrical systems.

Technical Information and Features

The Orion-Tr uses high-frequency switching technology to convert a wide-ranging 32–70V DC input into a regulated 24.2V nominal output. The output voltage can be adjusted between 20V and 30V, providing flexibility for different equipment and battery applications.

Galvanic isolation rated at 200V DC is provided between the input, output and case. This electrical separation helps prevent unwanted current paths between circuits and is particularly useful in marine, mobile and industrial installations.

The remote on/off connection allows the converter to be controlled using a low-power switch or an appropriate engine run signal. This removes the need for a high-current switch in the input wiring and makes integration with existing electrical control systems easier.

The unit is short-circuit protected and incorporates high-temperature protection. Its output current is reduced automatically at higher ambient temperatures to help protect the converter. Multiple compatible units can operate in parallel to increase output current, while screw-terminal connections allow straightforward installation without specialist connector tools.

The IP43 protection rating applies when the converter is installed with its screw terminals facing downwards.

Product Specifications

The Victron Energy ORI482410110 has an input voltage range of 32–70V DC, with undervoltage shutdown at 28V and restart at 30V. Its nominal output voltage is 24.2V DC, adjustable between 20V and 30V.

Continuous output current is rated at 5A at 25°C, with a maximum output current of 6.3A for 10 seconds. Short-circuit output current is 25A. Continuous output power is 120W at 25°C and 100W at 40°C. Maximum efficiency is 86%, and no-load input current is less than 60mA.

Output voltage tolerance is ±0.2V, with output noise of 2mV RMS. Galvanic isolation is rated at 200V DC between input, output and case. Current consumption when disabled through the remote connection is less than 200µA.

The operating temperature range is -20°C to +55°C, with output derating of 3% per °C above 40°C. Maximum permitted humidity is 95% non-condensing.

Electrical connections are made using screw terminals, with a maximum cable cross-section of 6mm² (AWG10). The unit measures approximately 100 x 113 x 47mm and weighs 0.42kg. Its protection rating is IP43 when installed with the screw terminals facing downwards.

Why Choose Victron Energy?

Victron Energy is internationally recognised for producing dependable power conversion and energy management equipment for demanding electrical applications. The Orion-Tr range combines reliable voltage regulation with practical installation features, making it a popular choice for marine, vehicle and off-grid power systems.

The Victron Orion-Tr 48/24-5A (120W) Isolated DC-DC Converter provides a dependable way to convert 48V battery power into a regulated 24V supply, with the added benefits of galvanic isolation, adjustable output voltage and remote switching.

SKU:ORI482410110
