Victron Energy Orion-Tr 48/24-16A (380W) Isolated DC-DC Converter – ORI482441110
Victron Energy Orion-Tr 48/24-16A (380W) Isolated DC-DC Converter – ORI482441110
Couldn't load pickup availability
Product Overview
The Victron Energy Orion-Tr 48/24-16A Isolated DC-DC Converter, part number ORI482441110, is a high-performance voltage converter designed to provide a regulated 24V DC supply from a 48V battery system. Delivering up to 16A of continuous output current and 380W of continuous power at 40°C, it is ideal for electrical installations requiring a dependable 24V supply from a higher-voltage battery bank.
Featuring galvanic isolation between the input, output and case, the Orion-Tr helps maintain electrical separation between different circuits. Its adjustable output voltage, remote on/off facility and parallel operation capability make it a versatile solution for marine, vehicle, industrial and off-grid electrical systems.
Usage and Applications
The Victron Orion-Tr 48/24-16A is suitable for installations where a 48V battery bank needs to power 24V electrical equipment. Typical applications include boats, motorhomes, commercial vehicles, renewable energy systems, industrial installations and off-grid battery storage systems.
It can provide a reliable 24V supply for compatible lighting, pumps, refrigeration equipment, communication systems, monitoring devices and industrial control equipment. Its adjustable output voltage allows the converter to be configured to suit different 24V electrical requirements.
The ORI482441110 is a voltage converter rather than a dedicated multi-stage battery charger. Where a 24V battery requires controlled charging, a suitable battery charger or charging-specific Victron Orion-Tr Smart model should be selected.
For larger installations, multiple compatible Orion-Tr converters can be connected in parallel to increase the available output current.
Technical Information and Features
The Orion-Tr uses high-frequency switching technology to convert a 48V DC input into a regulated 24.2V nominal output. The output voltage can be adjusted between 20V and 30V, providing flexibility when configuring the converter for different equipment and electrical systems.
Galvanic isolation rated at 200V DC is provided between the input, output and case. This electrical separation helps prevent unwanted current paths between circuits and is particularly beneficial in marine, vehicle and industrial installations.
The remote on/off connection allows the converter to be controlled using a low-power switch or an appropriate engine run signal. This eliminates the need for a high-current switch in the input wiring and makes integration with existing electrical control systems easier.
The unit incorporates short-circuit protection and high-temperature protection. Output current is automatically reduced at elevated ambient temperatures to help protect the converter. Multiple compatible units can operate in parallel to increase output capacity, while screw-terminal connections make installation straightforward without specialist connector tools.
The IP43 protection rating applies when the converter is installed with its screw terminals facing downwards.
Product Specifications
The Victron Energy ORI482441110 has an input voltage range of 40–70V DC, with undervoltage shutdown at 28V and restart at 30V. Its nominal output voltage is 24.2V DC, adjustable between 20V and 30V.
Continuous output current is rated at 16A at 40°C, with a maximum output current of 25A for 10 seconds. Short-circuit output current is 40A. Continuous output power is rated at 430W at 25°C and 380W at 40°C. Maximum efficiency is 89%, and no-load input current is less than 80mA.
Output voltage tolerance is ±0.2V, with output noise of 2mV RMS. Galvanic isolation is rated at 200V DC between input, output and case. Current consumption when disabled through the remote connection is less than 200µA.
The operating temperature range is -20°C to +55°C, with output derating of 3% per °C above 40°C. Maximum permitted humidity is 95% non-condensing.
Electrical connections are made using screw terminals, supporting cable cross-sections up to 16mm² (AWG6). The unit measures approximately 130 x 186 x 70mm and weighs 1.6kg. Its protection rating is IP43 when installed with the terminals facing downwards.
Why Choose Victron Energy?
Victron Energy is internationally recognised for producing dependable power conversion and energy management equipment for demanding electrical applications. The Orion-Tr range combines reliable voltage regulation with practical installation features, making it a popular choice for marine, vehicle and off-grid power systems.
The Victron Orion-Tr 48/24-16A Isolated DC-DC Converter provides an effective solution for converting 48V battery power into a regulated 24V supply, with the added benefits of galvanic isolation, adjustable output voltage and remote switching.
