Victron Energy Orion-Tr 48/12-30A (360W) Isolated DC-DC Converter – ORI481240110
Victron Energy Orion-Tr 48/12-30A (360W) Isolated DC-DC Converter – ORI481240110
Couldn't load pickup availability
Product Overview
The Victron Energy Orion-Tr 48/12-30A Isolated DC-DC Converter, part number ORI481240110, is a high-performance voltage converter designed to provide a regulated 12V DC supply from a 48V battery system. Delivering up to 30A of continuous output current at 40°C, this unit provides a dependable power solution for installations requiring a substantial 12V supply from a higher-voltage battery bank.
Featuring galvanic isolation between the input, output and case, the Orion-Tr helps maintain electrical separation between circuits. Its adjustable output voltage, remote on/off facility and parallel operation capability make it a versatile choice for marine, vehicle, industrial and off-grid electrical systems.
Usage and Applications
The Victron Orion-Tr 48/12-30A is suitable for electrical installations where 48V battery power needs to be converted into a regulated 12V supply. Typical applications include boats, motorhomes, commercial vehicles, renewable energy installations, industrial equipment and off-grid battery systems.
It can power compatible 12V equipment such as lighting, pumps, refrigeration systems, communication equipment, monitoring devices and other electrical accessories. The adjustable output voltage allows the converter to be configured to suit different 12V equipment requirements.
For installations with higher power demands, multiple compatible Orion-Tr converters can be connected in parallel to increase the available output current. This makes it particularly useful in larger DC electrical systems where a reliable 12V supply is required.
Technical Information and Features
The Orion-Tr uses high-frequency switching technology to convert a 48V DC input into a regulated 12.2V nominal output. The output voltage can be adjusted between 10V and 15V, providing flexibility when configuring the converter for different equipment.
Galvanic isolation rated at 200V DC is provided between the input, output and case. This electrical separation helps prevent unwanted current paths between circuits and is particularly beneficial in marine, mobile and industrial installations.
The remote on/off connection allows the converter to be controlled using a low-power switch or an appropriate engine run signal, eliminating the need for a high-current switch in the input wiring. The unit also incorporates short-circuit protection and high-temperature protection. Output current is automatically reduced at elevated ambient temperatures to help protect the converter.
The Orion-Tr supports parallel operation, allowing compatible units to be connected together to increase output capacity. Screw-terminal connections simplify installation, while the IP43 protection rating applies when the unit is mounted with its screw terminals facing downwards.
Product Specifications
The Victron Energy ORI481240110 has an input voltage range of 40–70V DC, with undervoltage shutdown at 28V and restart at 30V. Its nominal output voltage is 12.2V DC, adjustable between 10V and 15V.
Continuous output current is rated at 30A at 40°C, with a maximum output current of 40A for 10 seconds. Short-circuit output current is 60A. Continuous output power is rated at 430W at 25°C and 360W at 40°C. Maximum efficiency is 87%, and no-load input current is less than 80mA.
Output voltage tolerance is ±0.2V, with output noise of 2mV RMS. Galvanic isolation is rated at 200V DC between input, output and case. Current consumption when disabled through the remote connection is less than 200µA.
The operating temperature range is -20°C to +55°C, with output derating of 3% per °C above 40°C. Maximum permitted humidity is 95% non-condensing.
The converter uses screw-terminal DC connections and supports cable cross-sections up to 16mm² (AWG6). Its approximate dimensions are 130 x 186 x 80mm, and it weighs 1.8kg. The protection rating is IP43 when installed with the terminals facing downwards.
Why Choose Victron Energy?
Victron Energy is internationally recognised for producing dependable power conversion and energy management equipment for demanding electrical applications. The Orion-Tr range combines reliable voltage regulation with practical installation features, making it a popular choice for marine, vehicle and off-grid power systems.
The Victron Orion-Tr 48/12-30A (360W) Isolated DC-DC Converter is an effective solution for converting 48V battery power into a stable 12V supply, particularly where higher output current and galvanic isolation are required.
