Victron Energy ORI241210110 – Orion-Tr 24/12-9A (110W) Isolated DC-DC Converter
Victron Energy ORI241210110 – Orion-Tr 24/12-9A (110W) Isolated DC-DC Converter
Couldn't load pickup availability
The Victron Energy ORI241210110 Orion-Tr 24/12-9A is a high-quality isolated DC-DC converter designed to convert 24V DC power into a stable, adjustable 12V DC output. Delivering up to 9A of continuous output current and 110W of power, this compact converter provides a reliable solution for operating 12V electrical equipment from a 24V battery system.
Featuring galvanic isolation, adjustable output voltage and remote on/off functionality, the Victron Orion-Tr is ideal for vehicle, marine, commercial and off-grid electrical installations. Its robust design and dependable performance make it particularly suitable for applications where sensitive electrical equipment requires a consistent and regulated 12V supply.
Product Specifications
The ORI241210110 operates with a nominal 24V DC input and provides a nominal output voltage of 12.2V. The output voltage is adjustable between 10V and 15V, allowing the converter to be configured to suit different electrical equipment and battery requirements.
It delivers a continuous output current of 9A at 25°C, providing 110W of continuous output power. The maximum output current is 12.5A for up to 10 seconds under specified operating conditions.
The input voltage range is 16–35V DC, making it suitable for use with a wide range of 24V battery systems. The converter has an efficiency rating of approximately 85%, helping to minimise energy losses during voltage conversion.
Usage and Applications
The Victron Orion-Tr 24/12-9A converter is designed for installations where 12V electrical equipment needs to be powered from a 24V battery supply. It is particularly useful in commercial vehicles, motorhomes, boats, caravans, industrial machinery and off-grid electrical systems.
Typical applications include powering 12V lighting, communication equipment, navigation systems, monitoring devices, electronic controls and other compatible 12V appliances. Its regulated output helps maintain a stable power supply despite variations in the input voltage caused by battery charging or discharging.
The adjustable output voltage also allows the ORI241210110 to be used for charging a suitable 12V starter or auxiliary battery within a 24V electrical system, provided the charging voltage is configured correctly for the battery chemistry and manufacturer's requirements.
Technical Information
The ORI241210110 incorporates galvanic isolation rated at 200V DC between the input, output and case. This electrical separation helps prevent unwanted ground loops and reduces the transfer of electrical interference between connected circuits.
The integrated remote on/off facility allows the converter to be controlled using a low-power switch or an engine run/stop signal. This eliminates the need for a high-current switch in the main input wiring and makes installation more convenient in vehicle and marine electrical systems.
The converter includes short-circuit protection and high-temperature protection. When operating temperatures become excessive, the output current is automatically reduced to help protect the unit. Multiple compatible converters can also be connected in parallel to increase the available output current.
Undervoltage protection shuts down the converter when the input voltage falls to approximately 14V, with automatic restart at 15V. The unit has a no-load input current consumption of less than 40mA and an operating temperature range of -20°C to +55°C, with output derating above 40°C.
Electrical connections are made using screw terminals, allowing straightforward installation without specialist connection tools. The maximum cable cross-section is 6mm². The converter measures approximately 100 x 113 x 47mm and weighs around 0.42kg.
Its IP43 protection rating applies when installed with the screw terminals facing downwards. Maximum permitted humidity is 95%, non-condensing.
Why Choose the Victron Energy Orion-Tr ORI241210110?
The Victron Energy Orion-Tr 24/12-9A isolated DC-DC converter offers a dependable and efficient solution for converting 24V battery power into a regulated 12V supply. Its compact dimensions, adjustable output, galvanic isolation and remote switching capability make it a versatile choice for professional electrical installations.
Whether you are powering 12V accessories in a commercial vehicle, installing additional electrical equipment on a boat or integrating different battery voltages into an off-grid power system, the ORI241210110 provides the reliable voltage conversion and build quality associated with Victron Energy.
