Victron Energy Orion-Tr 24/12-15 DC-DC Converter 180W – ORI241215200

Victron Energy Orion-Tr 24/12-15 DC-DC Converter 180W – ORI241215200

Regular price £27.22 GBP
Regular price £43.20 GBP Sale price £27.22 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.


Product Overview

The Victron Energy Orion-Tr 24/12-15 DC-DC Converter (ORI241215200) is a compact, high-efficiency voltage converter designed to convert a 24V DC power supply into a regulated 12V output. Delivering a continuous output current of 15A and up to 180W of power, it provides a reliable solution for operating 12V electrical equipment from a 24V battery system.

Part of Victron Energy's Orion-Tr range, this non-isolated DC-DC converter uses advanced synchronous rectification technology to achieve an efficiency of up to 97%. Its compact construction, convenient screw-terminal connections and straightforward installation make it suitable for a wide range of marine, automotive, commercial vehicle and off-grid applications.

The Orion-Tr is designed to maintain a stable 12.5V output across a wide input voltage range of 18–35V DC. Its IP43 protection rating provides protection against water spray when installed with the screw terminals facing downwards.

Usage and Applications

The Victron Energy Orion-Tr 24/12-15 is designed to provide a reliable 12V DC supply from a 24V battery bank or power source. It allows compatible 12V electrical equipment to operate within a 24V installation without requiring a separate 12V battery system.

It is particularly suitable for boats, yachts, campervans, motorhomes, commercial vehicles, horseboxes, industrial machinery and off-grid electrical installations. Typical applications include powering 12V lighting, navigation instruments, communication equipment, monitoring systems, control equipment and other compatible electrical appliances.

For marine applications, the converter provides a practical way to operate 12V electronics from a 24V onboard electrical system. In commercial vehicles and motorhomes, it allows 12V accessories and appliances to operate directly from the vehicle's 24V supply.

With a continuous output current of 15A and a maximum output current of 20A, the Orion-Tr provides up to 180W of continuous power. This makes it suitable for installations with greater 12V electrical demands than smaller 5A and 10A converters. Multiple compatible Orion-Tr units can also be connected in parallel to increase the available output current.

Technical Information

The Orion-Tr 24/12-15 uses synchronous rectification technology to provide efficient DC-DC voltage conversion. It accepts an input voltage between 18V and 35V DC and produces a regulated 12.5V output.

With a continuous output current of 15A, the converter delivers up to 180W of continuous output power. Its maximum efficiency of 97% helps minimise energy losses and reduce unwanted heat generation during operation.

This is a non-isolated converter, meaning the input and output share a common negative connection. This should be taken into consideration when designing the electrical installation.

The converter features screw-terminal connections for straightforward installation without specialist tools. It is short-circuit proof and incorporates protection against overheating. An appropriately rated external fuse should be installed in the input supply.

The IP43 protection rating applies when the converter is mounted with its screw terminals facing downwards. Its operating temperature range is -20°C to +55°C, with output derating of 3% per °C above 40°C.

Product Specifications

Manufacturer: Victron Energy

Product Code: ORI241215200

Product Range: Orion-Tr

Product Type: Non-isolated DC-DC converter

Conversion: 24V DC to 12V DC

Nominal Input Voltage: 24V DC

Input Voltage Range: 18–35V DC

Output Voltage: 12.5V DC

Continuous Output Current: 15A

Maximum Output Current: 20A

Maximum Continuous Output Power: 180W

Maximum Efficiency: 97%

Galvanic Isolation: Non-isolated

Off-Load Current: Less than 35mA

Short-Circuit Protection: Yes

Protection Rating: IP43 when installed with terminals facing downwards

Operating Temperature Range: -20°C to +55°C

Temperature Derating: 3% per °C above 40°C

DC Connections: Screw terminals

Maximum Cable Cross-Section: 6mm²

Dimensions: 73 x 94 x 45mm

Weight: Approximately 250g

Colour: Blue (RAL 5012)

Warranty: 5 years

Why Choose Victron Energy?

Victron Energy is internationally recognised for producing high-quality power conversion, battery charging and energy management equipment for marine, automotive, industrial and off-grid applications.

The Orion-Tr 24/12-15 combines compact dimensions, excellent conversion efficiency and dependable voltage regulation in a practical DC-DC converter. Its 180W output capacity makes it an excellent choice for installations requiring a reliable 12V supply from a 24V battery system.

Whether upgrading an existing electrical installation or designing a new power system, the Victron Energy Orion-Tr provides an efficient and dependable solution for 24V to 12V voltage conversion.
