Victron Energy ORI121210110R – Orion-Tr 12/12-9A (110W) Isolated DC-DC Converter
Victron Energy ORI121210110R – Orion-Tr 12/12-9A (110W) Isolated DC-DC Converter
Couldn't load pickup availability
The Victron Energy ORI121210110R Orion-Tr 12/12-9A Isolated DC-DC Converter is a compact and efficient voltage conversion solution designed to provide a stable 12V DC output from a 12V electrical system. Delivering up to 9A of continuous output current and 110W of power, this versatile converter is ideal for marine, automotive, commercial and off-grid electrical installations.
Featuring galvanic isolation between the input, output and casing, the Orion-Tr provides electrical separation between connected circuits, helping prevent unwanted ground loops and electrical interference. Its adjustable output voltage, remote on/off functionality and integrated protection features make it a reliable choice for applications requiring a regulated DC power supply.
The ORI121210110R is the retail version of the Victron Orion-Tr 12/12-9A isolated converter, supplied with the same core electrical specifications and functionality.
Product Overview and Usage
The Victron Energy Orion-Tr 12/12-9A converter is designed to maintain a consistent 12V output, even when the input voltage fluctuates. This makes it particularly useful in electrical systems where battery voltage changes during charging and discharging.
The adjustable output voltage allows the converter to be configured between 10V and 15V, making it suitable for supplying stable power to 12V electronic equipment, communication systems, lighting, control equipment and other compatible DC-powered devices.
Its galvanically isolated design provides electrical separation between the input and output circuits. This is especially valuable in marine installations, commercial vehicles and specialist electrical systems where separate circuits need to remain electrically isolated.
The unit can also be configured to provide a suitable charging voltage for a 12V starter or accessory battery in certain applications, including installations where a 24V system supplies a separate 12V battery. However, it does not incorporate a dedicated multi-stage battery charging algorithm and should not be confused with a smart DC-DC battery charger.
The Orion-Tr is suitable for motorhomes, campervans, boats, commercial vehicles, industrial equipment and off-grid electrical systems where dependable voltage conversion is required.
Technical Information and Features
The ORI121210110R operates with an input voltage range of 8–17V DC and provides a nominal output voltage of 12.2V DC. The output voltage can be adjusted between 10V and 15V, allowing the converter to be configured for different electrical applications.
It delivers a continuous output current of 9A at nominal output voltage, providing 110W of continuous output power at 25°C. At an ambient temperature of 40°C, the continuous output power is rated at 85W.
The maximum output current is 12.5A for up to 10 seconds, while the short-circuit output current is rated at 32A. Maximum conversion efficiency is approximately 87%, helping minimise energy losses during operation.
Galvanic isolation is rated at 200V DC between the input, output and casing. This electrical separation helps reduce ground-loop problems and unwanted electrical interference between connected systems.
The integrated remote on/off connection eliminates the need for a high-current switch in the main input wiring. It can be operated using a low-power switch or a suitable engine run/stop signal.
Multiple Orion-Tr converters can be connected in parallel to increase the available output current, allowing installations to be expanded where additional power capacity is required.
Additional protection includes short-circuit protection and high-temperature protection, with output current automatically reduced when operating temperatures become elevated.
Product Specifications
The Victron Energy ORI121210110R has a nominal input voltage of 12V DC and a nominal output voltage of 12.2V DC. Its input voltage operating range is 8–17V, with undervoltage shutdown at 7V and restart at 7.5V.
The adjustable output voltage range is 10–15V DC, with an output voltage tolerance of ±0.2V and output noise of approximately 2mV RMS.
The continuous output current is 9A at nominal output voltage, with a maximum output current of 12.5A for up to 10 seconds. Short-circuit output current is 32A.
Continuous output power is rated at 110W at 25°C and 85W at 40°C, with a maximum efficiency of approximately 87%.
Galvanic isolation is rated at 200V DC between the input, output and casing. The operating temperature range is -20°C to +55°C, with output derating above 40°C. Maximum permitted humidity is 95% non-condensing.
Electrical connections are made using screw terminals supporting cable sizes up to 6mm². The unit measures approximately 100 x 113 x 47mm and weighs approximately 0.42kg. It has an IP43 protection rating when installed with the screw terminals facing downwards.
Ideal Applications
The Victron Energy Orion-Tr 12/12-9A Isolated DC-DC Converter is suitable for marine electrical systems, motorhomes, campervans, commercial vehicles, boats, industrial equipment and off-grid installations.
Its compact dimensions make it particularly useful where installation space is limited, while galvanic isolation provides additional flexibility when integrating separate electrical circuits.
Whether used to supply stable power to sensitive electronic equipment or as part of a larger DC electrical installation, the Orion-Tr provides dependable voltage conversion and regulation.
Why Choose Victron Energy?
Victron Energy is internationally recognised for manufacturing high-quality inverters, battery chargers, DC-DC converters and professional power management equipment. Its products are widely used in marine, automotive, commercial and renewable energy applications.
The ORI121210110R combines reliable voltage regulation, galvanic isolation and flexible installation options in a compact design. It is an excellent choice for users and professional installers looking for a dependable 12V isolated DC-DC converter.
