Victron Energy MultiPlus 24/800/16-16 230V VE.Bus Inverter Charger – PMP241800000

Product Description

The Victron Energy MultiPlus 24/800/16-16 230V VE.Bus is a compact inverter/charger designed for 24V battery systems that require dependable 230V AC power and integrated battery charging. Combining a pure sine wave inverter, a 16A battery charger and an automatic 16A AC transfer switch, it offers a practical all-in-one solution for marine, mobile, off-grid and backup-power applications.

With an 800VA inverter rating and a continuous active output of 700W at 25°C, the MultiPlus can power a range of compatible electrical equipment within its operating limits. When connected to an external AC supply, the integrated charger recharges the battery while the transfer switch supplies connected AC loads.

The VE.Bus communication interface supports configuration and integration with compatible Victron Energy equipment.

Pure Sine Wave Inverter

The MultiPlus converts 24V DC battery power into 230V AC pure sine wave electricity. This makes it suitable for a variety of compatible electronic devices and electrical appliances, subject to their power requirements and start-up currents.

Integrated Battery Charger

The built-in 16A battery charger supports charging of a suitable 24V battery bank from an external AC supply. Adaptive multi-stage charging helps manage the charging process. Charging parameters must be selected to suit the connected battery chemistry and manufacturer's recommendations.

Automatic AC Transfer Switch

When external AC power is available, the MultiPlus can supply connected loads through its transfer switch and charge the battery. If the external supply fails, the inverter automatically takes over, helping maintain continuity of power for suitable connected equipment.

The 16A transfer switch is intended for installations with appropriately rated AC supply and distribution equipment.

Key Features and Benefits

• 800VA inverter capacity: Provides up to 700W continuous active output at 25°C.

• Pure sine wave output: Supplies 230V AC power for compatible electrical equipment.

• 24V DC battery input: Designed for compatible 24V battery systems.

• 16A integrated battery charger: Recharges a suitable battery bank from an external AC source.

• 16A AC transfer switch: Automatically switches between external AC and inverter power.

• UPS functionality: Rapid changeover helps maintain supply to compatible equipment during AC interruptions.

• Adaptive charging technology: Supports intelligent multi-stage battery charging.

• VE.Bus communications: Enables configuration and integration with compatible Victron equipment.

• Compact design: Suitable for installations where mounting space is limited.

• Integrated protection: Includes protection against overload, short circuit, excessive temperature and abnormal battery voltage.

Technical Specifications

Product identification

• Brand: Victron Energy

• Product range: MultiPlus

• Model: MultiPlus 24/800/16-16 230V VE.Bus

• Manufacturer part number: PMP241800000

• Product type: Inverter, battery charger and automatic AC transfer switch

Inverter specifications

• Nominal battery voltage: 24V DC

• DC input voltage range: 19–33V DC

• Continuous apparent power at 25°C: 800VA

• Continuous active power at 25°C: 700W

• Peak power: 1,600W

• AC output voltage: 230V AC ±2%

• Output frequency: 50Hz ±0.1%

• Output waveform: Pure sine wave

• Maximum efficiency: Approximately 92%

• Zero-load power consumption: Refer to the manufacturer's datasheet for the applicable specification

Battery charger specifications

• Maximum battery charge current: 16A

• Nominal battery system: 24V

• Typical absorption voltage for a compatible lead-acid configuration: 28.8V DC

• Typical float voltage for a compatible lead-acid configuration: 27.6V DC

• Typical storage voltage for a compatible lead-acid configuration: 26.4V DC

• Charging method: Adaptive multi-stage charging

Charging voltages are typical settings for compatible lead-acid batteries and may vary with configuration. Always use the correct charging profile for the connected battery.

AC input and transfer specifications

• Nominal AC output: 230V

• AC input voltage range: 187–265V AC

• AC input frequency range: 45–65Hz

• AC transfer switch rating: 16A

• Automatic AC changeover: Yes

General specifications

• Communication interface: VE.Bus

• AC connection: G-ST18i plug connection

• Protection rating: IP21

• Dimensions (H × W × D): Approximately 360 × 240 × 100mm

• Weight: Approximately 6.4kg

Typical Applications

The Victron Energy MultiPlus 24/800/16-16 is suitable for small 24V systems requiring modest AC power and integrated battery charging, including:

• Small boats and marine electrical systems

• Campervans and specialist vehicles using 24V systems

• Small off-grid installations

• Remote communications and monitoring equipment

• Low-power backup systems

• Battery-based mobile power installations

• Applications requiring a compact inverter and charger combination

The 800VA rating makes this model best suited to relatively low-power equipment. Appliances with motors, compressors or high start-up currents should be checked against the inverter's capacity before use.

Installation and Compatibility

The MultiPlus is designed for integration into a compatible 24V battery-based electrical system. The battery bank, DC cables, fuses, isolators and connections must be appropriately rated for the expected current.

AC input and output wiring must comply with the manufacturer's installation instructions and applicable electrical regulations. Suitable isolation, circuit protection, earthing and ventilation are important for safe operation.

VE.Bus communications support configuration using compatible Victron equipment and software. Additional monitoring or remote-control functions may require compatible accessories.

Installation and commissioning should be carried out by a suitably qualified professional.

Important compatibility note: PMP241800000 identifies the 24V MultiPlus 24/800/16-16 230V model. It is not designed for direct connection to a 12V battery bank. Check the complete part number and system voltage before ordering.
