Victron Energy ASS000200100 – CAN-bus Temperature Sensor
Victron Energy ASS000200100 – CAN-bus Temperature Sensor
Couldn't load pickup availability
The Victron Energy ASS000200100 CAN-bus Temperature Sensor is a specialist battery temperature monitoring accessory designed to work with Victron Energy Buck-Boost DC-DC converters. It provides accurate battery temperature information to compatible Victron equipment, helping protect lithium battery systems from charging at temperatures that could cause permanent damage.
Particularly important for installations using Lithium Iron Phosphate (LiFePO4 or LFP) batteries, this intelligent temperature sensor monitors battery temperature and communicates directly with the connected charging equipment via CAN-bus. When temperatures become too low, the system can automatically reduce or stop charging to help protect battery cells and maintain safe operating conditions.
Suitable for professional marine, automotive, motorhome, campervan and off-grid electrical installations, the Victron ASS000200100 provides an additional level of protection for advanced battery charging systems.
Product Overview and Usage
Lithium batteries require careful temperature management during charging. Unlike conventional lead-acid batteries, LiFePO4 batteries must not be charged when their temperature falls below the manufacturer's permitted charging threshold. Charging lithium batteries at very low temperatures can cause permanent cell damage and reduce battery performance and service life.
The Victron Energy CAN-bus Temperature Sensor addresses this requirement by continuously monitoring the battery temperature and transmitting the information to a compatible Buck-Boost DC-DC converter. When the battery temperature drops below approximately 5°C, the charging current needs to be reduced. If the temperature falls below 0°C, charging must stop.
The connected Victron equipment can use this temperature information to automatically adjust or suspend charging, helping prevent potentially damaging low-temperature charging conditions.
The sensor can also be connected to the temperature sensor terminal on compatible Victron MultiPlus and Quattro inverter/chargers, allowing these devices to regulate or stop charging according to battery temperature.
This makes the ASS000200100 particularly useful in campervans, motorhomes, boats, commercial vehicles and off-grid installations where lithium battery banks may be exposed to cold operating conditions.
Technical Information and Features
The Victron Energy ASS000200100 uses CAN-bus communication to transmit battery temperature information to compatible Victron equipment. It features a dedicated temperature monitoring function and an integrated alarm output that can be used to control external equipment when a programmed temperature threshold is reached.
The alarm output operates through pin 5 and switches to ground when activated, supporting the control of suitable external loads or warning systems.
The sensor has a supply voltage range of approximately 4–36V DC, making it suitable for a range of 12V and 24V electrical installations. Its current consumption is approximately 60mA at 13.6V.
The temperature threshold can be programmed using compatible configuration software connected to the Buck-Boost converter. LED indicators provide visual operating status information.
Product Specifications
The Victron Energy ASS000200100 CAN-bus Temperature Sensor has a supply voltage of 4–36V DC and a current consumption of 60mA at 13.6V. Its alarm output is rated at 350mA and switches to ground through pin 5.
The unit measures approximately 57.6 x 40 x 15.8mm, including connectors, and weighs approximately 12g. It uses CAN-bus communication for transmitting temperature information to compatible Victron equipment.
The sensor is designed for use with Victron Buck-Boost DC-DC converters and is also compatible with the temperature sensing connections on suitable MultiPlus and Quattro inverter/chargers.
Why Choose Victron Energy?
Victron Energy is internationally recognised for its high-quality battery charging, power conversion and energy management equipment. Its products are widely used in professional marine, automotive, commercial and renewable energy installations.
The Victron Energy ASS000200100 CAN-bus Temperature Sensor is an important accessory for lithium battery installations requiring temperature-controlled charging. By providing accurate battery temperature information to compatible Victron equipment, it helps protect valuable battery systems and supports safe, reliable operation in demanding environments.
